Digital Joulemeter and Wattmeter Manufacturer,Supplier and Exporter
Product Code : SEL-PLE-10145
Quick Answer: Light and compact, this digital joulemeter and wattmeter measures the energy taken by an AC or DC load from 1J to 999,999J, or 1mJ to 999,999mJ, and power from 200mW to 200W, for class demonstration or student use.
Last updated: October 2026
Key Features
- Measures energy taken by a load on AC or DC
- Energy from 1J to 999,999J or 1mJ to 999,999mJ
- Power from 200mW to 200W
- 6-digit energy and power indication
- Pair of 4mm sockets to indicate the instantaneous power; 1V full scale deflection represents 100mW or 100W, depending on range
- Maximum current 10A AC/DC
Technical Specifications
| Specification | Value |
|---|---|
| Input voltage | 0 to 15V AC (0 to 21V DC); absolute maximum 35V DC, 24V AC |
| Input frequency | 0 to 500Hz maximum |
| Maximum current | 10A AC / DC |
| Energy range | 1J to 999,999J or 1mJ to 999,999mJ |
| Power range | 200mW to 200W |
| Accuracy | 5%, typically better than 3% at full scale |
| Display | 6 digits |
| Power supply | 220V A.C. 50/60Hz |
| Dimensions | 208x155x115mm |
About This Product
Measuring electrical energy directly saves students from multiplying voltage, current and time by hand, and lets them compare that calculation with the meter reading. The unit is light and compact, designed for class demonstration or student use, and its pair of 4mm sockets indicates the instantaneous power alongside the 6-digit energy and power indication.
Frequently Asked Questions
Can it measure AC and DC loads?
Yes. It measures the energy taken by a load on either AC or DC, within an input of 0 to 15V AC or 0 to 21V DC and a maximum current of 10A.
What are the 4mm sockets for?
They indicate the instantaneous power: 1V full-scale deflection represents 100mW or 100W, depending on the range selected.
