Stereoscopic Microscope Manufacturer,Supplier and Exporter
Product Code : SEL-M-10850
Quick Answer: Used for three-dimensional viewing of whole specimens, this stereoscopic microscope has paired widefield 10x inclined eyepieces, achromatic 1x and 3x objectives on a locking turret and an 80mm frosted glass stage plate.
Last updated: October 2026
Key Features
- Paired widefield 10x inclined eyepieces with dioptre and interpupillary adjustment
- Achromatic, parfocal and parcentred 1x and 3x objectives on a rotating, locking turret
- Rack and pinion focusing with slip clutch and tension adjustment
- 360° rotating and locking viewing head
- 80mm reversible black/white contrast plate and 80mm frosted glass stage plate
- Cast metal frame, 14.5 inch (37 cm), with locked-on stage clips and a blue filter for transmitted light
Technical Specifications
| Specification | Value |
|---|---|
| Eyepieces | Paired widefield 10x, inclined, dioptre and interpupillary adjustment |
| Objectives | Achromatic 1x and 3x, parfocal and parcentred, rotating locking turret |
| Focusing | Rack and pinion, slip clutch, tension adjustment |
| Viewing head | 360° rotating and locking |
| Stage plates | 80mm reversible black/white contrast plate; 80mm frosted glass plate |
| Frame | Cast metal, 14.5 inch (37 cm) |
| Accessories | Locked-on stage clips, blue filter for bottom light |
About This Product
A stereoscopic microscope gives a three-dimensional view of whole specimens, here through paired 10x eyepieces and 1x and 3x objectives. The two stage plates offer several viewing options with the multi-angle illumination: a reversible black or white contrast plate, and a frosted glass plate used with transmitted light from below. Because the objectives are parfocal, the specimen stays roughly in focus when switching between 1x and 3x. School Educational Instrument can supply the Stereoscopic Microscope to schools and colleges in Ecuador, Kuwait, Vietnam, France, Montenegro and Albania.
Frequently Asked Questions
What can be placed on the stage?
There is an 80mm reversible black and white contrast plate and an 80mm frosted glass stage plate, giving several viewing options, with locked-on stage clips to hold the specimen and a blue filter for transmitted light.
Can the eyepieces be adjusted for each user?
Yes. The paired widefield 10x inclined eyepieces have dioptre and interpupillary adjustments, and the viewing head rotates through 360° and locks.
Related: Microscopes, Student Stereo Microscope, Universal Stereoscopic Binocular Microscope, Stereoscopic Zoom Binocular and Trinocular Microscope.
For a quotation on the Stereoscopic Microscope, contact School Educational Instrument.
