Cordless Compound Monocular Microscope Manufacturer,Supplier and Exporter
Product Code : SEL-M-10899
Quick Answer: Interchangeable 10x and 25x wide-field eyepieces and upper and lower LED lighting make this cordless compound monocular microscope suited to both slides and solid specimens in biology teaching.
Last updated: October 2026
Key Features
- Monocular head with interchangeable 10x and 25x wide-field eyepieces
- Fixed 45-degree inclination with 360-degree rotation for sharing
- Forward-facing nosepiece with 4x, 10x and 40x DIN achromatic full-glass objectives
- Brightfield upper and lower LED illumination with rheostat
- 0.65 NA single-lens condenser with disc diaphragm
- Coaxial coarse and fine focus; plain stage with clips and stage stop
Technical Specifications
| Specification | Value |
|---|---|
| Head | Monocular, 45-degree, 360-degree rotation |
| Eyepieces | 10x and 25x wide-field, interchangeable |
| Nosepiece | Forward-facing |
| Objectives | 4x, 10x, 40x DIN achromatic, full glass |
| Condenser | Single lens, 0.65 NA, disc diaphragm |
| Illumination | Brightfield, upper and lower LED, rheostat |
| Focusing | Coaxial coarse and fine |
| Stage | Plain, with stage clips and stage stop |
About This Product
Lighting from both above and below lets the same microscope show a prepared slide by transmitted light and the surface of a seed or insect by reflected light. Changing to the 25x eyepiece raises the magnification of every objective without buying another instrument. The stage stop sets a limit on stage travel, which protects slides and objectives when students focus quickly, and the rotating head can be turned toward a partner.
Frequently Asked Questions
Which eyepieces come with the Cordless Compound Monocular Microscope?
It has interchangeable 10x and 25x wide-field eyepieces, used with 4x, 10x and 40x DIN achromatic objectives.
What illumination does it have?
Brightfield upper and lower LED lighting with a rheostat, and a 0.65 NA single-lens condenser with a disc diaphragm.
Related: Microscopes, LED Cordless Beginner Monocular Microscope, Monocular Coaxial Focusing Beginner Microscope, LED Kohler Illumination Monocular Microscope.
For a quotation on the Cordless Compound Monocular Microscope, contact School Educational Instrument.
