ICU Ventilator Manufacturer,Supplier and Exporter
Product Code : SEL-SPW-11868
School Educational Instrument is a leading ICU Ventilator Manufacturer,suppliers and Exporter
An Optimal Combination of Invasive and Noninvasive Ventilator :-
As noninvasive ventilation, it is used increasingly in a wide range of clinical situations, we offer a dual solution AN359 which combines the advantages of a flexible noninvasive ventilator with a full-featured invasive ventilator for the ICU
Ventilation Modes :-
VCV(A/C), PCV(A/C), PRVC, SIMV(VCV)+PSV, SIMV(PCV)+PSV, SIMV(PRVC)+PSV, SPONT/CPAP +PSV, BIVENT +PSV, NIV/CPAP, NIV-T, NIV-S/T
Parameters :-
Respiration Rate:1~80 bpm
Tinsp:0.2~9 s
Tidal Volume:20~2000 ml
Tpause:0~4 s
Tslope:0~2 s
I:E Ratio:1:10~4:1
Trigger Sensitivity:0~35 cmH2O
FiO2: Pressure (-20~0 cmH2O, above PEEP), Flow (0.5~20 LPM)
PEEP:
Psupport: 0~70 cmH2O
Pinsp:5~70 cmH2OMonitoring
Pressure Value: Ppeak, Pplat, Pmean, Pmin, PEEP
Volume / Flow Value: Vti, Vte, MV, MVspont
Time Value:ftotal,fspont, I:E
Gas Monitoring: FiO2, ETCO2
Calculated Values: Compliance(C), Resistance(R) MVleak, RSBI, WOB, PEEPi
Real Time Curves:Pressure-Time, Flow-Time, Volume-Time waveforms, Pressure-Volume, Volume-Flow, Flow-Pressure loops
Alarm:-
Paw high/low MVe high/low Circuit disconnnect
FiO2 high/low Inspiration/Expiratory tidal volume low
High Respiration Rate Apnea AC Failure Nebulizer On
Low Battery Air /O2 supply down High/Low PEEP
Leakage out of range Occlusion
Technical Data :-
Screen:12〞TFT color touch screen (detachable)
Supply Gas:O2, 0.28~0.6 MPa
Dimension (Width x Depth x Height):322 mm x 375 mm x 366 mm (Main Unit), 547 mm x 675 mm x 950 mm (Cart)
Weight:12.5 kg (Main Unit), 25 kg (Cart)
Power Supply: AC100~240 V, 50 Hz/60 Hz
Communication Interface: RS-232 Port, Nurse call Port, Ethernet Port
Superior Mobile ICU ventilator :-
Comprehensive ICU ventilator including BIVENT and PRVC
Compact, big capacity battery, no air compressor, intra-hospital mobility
Flexible device configuration: equipped on a trolley, bed or ceiling pendant
Cost Effective Solution:-
Unique metal-based, autoclavable, heated exhalation valve
Built-in flow sensor, non-consumable design
Upgradeable ventilation system software, with an available USB port
Optimal patient-ventilator synchrony, increase patient comfort
The Unique Leak Compensation System - Keep precise control on the tidal volume of each breath delivered to the patient by adjusting compensation dosage automatically
Advanced Trigger Technique - Enhance sensitivity, avoid spurious triggering
Safe Ventilation Through Whole Treatment Phase Initial Treatment Phase
Noninvasive ventilation mode associated with decreased intubation rates, shortened patient stays, improved patient comfort, and a reduced risk of cross infection
Preset patient’s height and IBW. Reduce clinician’s workload
Stable Condition Phase :-
PRVC and BIVENT employ lung-protective strategies, delivering intelligent ventilation
Comprehensive lung mechanics monitoring include compliance, airway resistance, PEEPi and time constant
Three waveforms & three loops with user-friendly display provide a continuous monitoring of the patient’s condition
Weaning Phase :-
Various ventilation modes enhance the weaning process
The unique trigger and leakage compensation system safeguards each and every patient breath resulting in smooth and comfortable breathing, avoiding extra workload on the patient and promoting recovery
RSBI and WOB provide accurate reference for weaning
Rehab Phase :-
Data export port provides connection to hospital monitors and Patient Data Management Systems
Provides pressure support for the patient when spontaneous breathing is present
