Digitized Semiconductor Curve Tracer Manufacturer,Supplier and Exporter
Product Code : SEL-TILE-10963
Quick Answer: Characteristic curves of semiconductor devices appear on the built-in TFT LCD touchscreen of this digitized curve tracer, which generates 8 sets of digital curves in 1 second without an oscilloscope or PC.
Last updated: October 2026
Key Features
- Generates 8 sets of digital curves on the LCD screen in 1 second
- Built-in TFT LCD touchscreen, no PC or oscilloscope required
- Touchscreen set-up of device type, voltage bias, current steps and other conditions
- Two sets of test sockets for switching between two devices and comparing them
- Saves and reloads up to 8 sets of previous curves
- USB port to load data into a PC; optional connection to an external scope for real-time measurement
Technical Specifications
| Specification | Value |
|---|---|
| Display | Built-in TFT LCD touchscreen |
| Curve generation | 8 sets of digital curves in 1 second |
| Curve memory | Save and reload up to 8 sets |
| Test sockets | Two sets |
| Settings | Device type, voltage bias, current steps, etc. |
| PC link | USB port |
| External scope | Optional, for real-time measurement |
About This Product
Two test sockets are the key to quick comparison here: a student can fit one device in each and switch between them for rapid testing and curve comparison. Measuring conditions are set with touchscreen buttons, results stay on the TFT display without a separate oscilloscope, and up to 8 stored curve sets can be recalled for revision. Captured curve data can also be saved to a PC over the USB port in an electronics or engineering lab.
Frequently Asked Questions
Does the curve tracer need a PC or oscilloscope?
No. Results are displayed on the built-in TFT LCD screen. A PC can be used to save data via the USB port, and an external scope can be connected for real-time measurement.
How many curves can be stored?
A maximum of 8 sets of previous curves can be saved and reloaded for revision and comparison.
Related: Testing Instrument Lab Equipment, Differential Active Probe, Training Bench.
For a quotation on the Digitized Semiconductor Curve Tracer, contact School Educational Instrument.
