Advanced Research Polarizing Microscopes Manufacturer,Supplier and Exporter
Product Code : SEL-M-10883
Quick Answer: Built for advanced polarised-light work, this research polarising microscope has strain-free colour-corrected optics, Koehler transmitted plus incident illumination, a graduated large circular rotary stage and retarding plates including a λ plate, 1/4 λ mica plate and quartz wedge.
Last updated: October 2026
Key Features
- Rugged single die-cast body, ergonomic design
- Strain-free, colour-corrected achromatic optics with multi-layer hard anti-fungal, anti-bacterial coating
- Koehler transmitted illumination (halogen/LED), intensity adjustable, battery backup and auto cut-off
- Incident LED/halogen illumination with aperture and field diaphragm
- Rotatable analyser with scale, removable from the light path; focusable, centrable Bertrand lens
- Graduated large circular rotary stage; reverse centrable quadruple/quintuple nosepiece with M25 x 0.75 threads
Technical Specifications
| Specification | Value |
|---|---|
| Body | Single die cast, ergonomic, touch-point treated |
| Optical system | Strain-free achromatic, colour corrected, multi-layer hard coated |
| Transmitted illumination | Koehler halogen/LED, adjustable, battery backup, auto cut-off |
| Incident illumination | LED/halogen, aperture and field diaphragm |
| Analyser | With scale, rotatable, removable; focusable and centrable Bertrand lens |
| Retarding plates | λ plate, 1/4 λ (mica), quartz wedge |
| Viewing head | Monocular, binocular or trinocular |
| Nosepiece | Reverse centrable quadruple/quintuple, M25 x 0.75 threads, ball bearing, click stop |
| Objectives | POL plan, S-APO/APO, infinity |
| Stage | Graduated large circular rotary |
| Condenser | Abbe with iris diaphragm and filter slot |
| Focusing | Low-position coaxial, both sides, tension control, upper limit stopper |
About This Product
Koehler transmitted illumination and incident LED/halogen illumination with aperture and field diaphragm let this stand work in both light paths, for brightfield and polarising observation. The graduated large circular rotary stage turns the specimen under strain-free, colour-corrected achromatic optics, with a rotatable analyser and a focusable, centrable Bertrand lens. A monocular, binocular or trinocular head can be chosen for work in college and research labs.
Frequently Asked Questions
Which retarding plates does it have?
The retarding plates are a λ plate, a 1/4 λ mica plate and a quartz wedge.
Can it examine opaque samples?
Yes. In addition to Koehler transmitted illumination, it has incident LED/halogen illumination with aperture and field diaphragm for reflected-light work.
Which viewing heads are offered?
The microscope is offered with a monocular, binocular or trinocular viewing head and extra wide-field eyepieces with dioptre adjustment.
Related: Microscopes, Laboratory Polarising Microscope, Laboratory Ore Microscope, Inclined Ore Microscope.
For a quotation on the Advanced Research Polarizing Microscopes, contact School Educational Instrument.
