Spherometer Demonstration Model Manufacturer,Supplier and Exporter
Product Code : SEL-PLE-10132
Quick Answer: Used for the precise measurement of the radius of curvature of spherical lenses, this spherometer has a 1 mm pitch central screw and a 100-division disc that together give a least count of 0.01 mm.
Last updated: October 2026
Key Features
Three-pronged table on three pointed legs
Vertical main scale from 10 - 0 - 10 mm on one prong
Micrometer scale on a circular brass disc with 100 divisions
Central screw with a pitch of 1 mm
Least count 0.01 mm
Technical Specifications
Specification
Value
Table
Three-pronged, three pointed legs
Main scale
Vertical, 10 - 0 - 10 mm
Circular scale
Brass disc, 100 divisions
Screw pitch
1 mm
Least count
0.01 mm
About This Product
A spherometer gives students a hands-on way to find the radius of curvature of a spherical lens during optics practicals in school and college labs. The three pointed legs rest on the surface while the central screw is turned, and dividing the 1 mm pitch by the 100 divisions on the brass disc shows clearly where the 0.01 mm least count comes from.
Frequently Asked Questions
What is the least count of this spherometer?
The centre screw has a pitch of 1 mm and the circular brass disc has 100 divisions, giving a least count of 0.01 mm.
What is a spherometer used for?
It is used for the precise measurement of the radius of curvature of spherical lenses.
