Friction Board Inclined Plane Manufacturer,Supplier and Exporter
Product Code : SEL-PLE-10144
Quick Answer: Hinged at one end with a pulley for the force cord at the other, this 600 x 75mm friction board has a variable inclination that is locked into position by a screw clamp with pointer and read from its angle plate.
Last updated: October 2026
Key Features
Plane board 600 x 75mm, hinged at the base at one end
Pulley for the force cord at the other end
Attached angle measuring plate with clear increments
Variable inclination locked by a screw clamp with pointer
Supplied with scale pan, two slides and a 75 x 25mm metal roller
Technical Specifications
Specification
Value
Board
600 x 75mm
Angle setting
Angle plate, screw clamp with pointer
Accessories
Scale pan, two slides, 75 x 25mm metal roller
Weight
2.4 kg
About This Product
The inclination of the board can be varied and read from the angle plate, and the pulley at the end opposite the hinge carries the force cord. A scale pan, two slides and a 75 x 25mm metal roller are supplied for use with the board, which together suit friction and inclined plane practicals in school and college labs.
Frequently Asked Questions
How is the angle of the plane set and read?
The inclination is variable and is locked by a screw clamp with a pointer, and the selected angle is read on the attached angle measuring plate.
What accessories come with the board?
A scale pan, two slides and a 75 x 25mm metal roller.
