Pressure Measurment Apparatus Manufacturer,Supplier and Exporter
Product Code : SEL-FMM-11049
Quick Answer: Five basic types of pressure device are coupled to an orifice meter on the Pressure Measurment Apparatus, so students can measure pressures and study the working and operating principle of each device.
Last updated: October 2026
Key Features
- Single well manometer: 0-25 mm limb, 0-30 mm cup
- Inclined U-tube manometer: 0-30 mm limb and 0-30 mm inclined limb
- Acrylic differential manometer, 250-0-250 mm
- Pressure gauge, 0-4 kg/cm2
- Vacuum gauge, 0-760 mmHg
- Flow control valve to change pressure
Technical Specifications
| Specification | Value |
|---|---|
| Single well manometer | 0-25 mm (limb), 0-30 mm (cup) |
| Inclined U-tube manometer | 0-30 mm (limb), 0-30 mm (inclined limb) |
| Differential manometer | Acrylic, 250-0-250 mm |
| Pressure gauge | 0-4 kg/cm2 |
| Vacuum gauge | 0-760 mmHg |
| Sump tank | 900 x 350 x 350 mm |
About This Product
Having liquid-column manometers and mechanical pressure and vacuum gauges on one circuit gives students a side-by-side introduction to the main ways pressure is measured. Changing the pressure with the control valve produces a spread of readings, and working through each device in turn shows how it operates and what range it covers. School Educational Instrument can ship the Pressure Measurment Apparatus to Argentina, the Republic of the Congo, North Macedonia, Syria and the Solomon Islands.
Frequently Asked Questions
Which pressure devices are fitted?
A single well manometer, an inclined U-tube manometer, an acrylic differential manometer (250-0-250 mm), a pressure gauge (0-4 kg/cm2) and a vacuum gauge (0-760 mmHg), all coupled to an orifice meter.
